艾迈斯 TMF8829 48x32 multi-zone Time-of-Flight sensor
The TMF8829 is a direct time-of-flight (dToF) sensor with configurable resolution of 8x8, 16x16, 32x32 & 48x32. The device is based on SPAD, TDC, and histogram technology and achieves a detection range of up to 11000 mm with an 80° field of view. All processing of the raw data is performed on-chip, and the TMF8829 provides distance information along with confidence values, signal amplitude, and ambient light on its interface. Internally, the TMF8829 uses dToF histograms and peak detection, and therefore, it is highly tolerant to smudges on the cover glass. Additionally, the TMF8829 can handle multiple objects per depth point simultaneously without degrading accuracy. It reports the distance of all depth points with a resolution of 0.25 mm. The device uses an I3C (I²C compatible) communication interface and a fully featured SPI interface for control and raw data streaming. A VBUS supply pin allows operation of the I²C/I3C or SPI with 1.2V, 1.8V, or 3V I/O supplies. Raw data streaming, including all algorithm peak detection results, allows further processing on the host for “AI-enabled” applications. The TMF8829 is a fully contained optical module measuring only 5.7 mm x 2.9 mm x 1.5 mm.
Watch the TMF8829 product overview video to discover more
TMF8829 Overview Video
